Optimizing Docker Deployment on Proxmox: Practical Approaches for Performance and Reliability

A recurring scenario: a team aims to consolidate bare-metal workloads, but the Docker-on-Proxmox debate resurfaces. LXC for footprint, KVM for true isolation—but what’s the optimal setup?

Below—field-tested strategies, recommended configurations, and relevant caveats for running Docker under Proxmox VE (≥7.4) in production-like environments. Skip generic walkthroughs; focus on technical trade-offs, non-obvious tips, and operational best practices.

Why Layer Docker on Proxmox?

On physical hosts, Docker’s own container isolation suffices. Under Proxmox VE, running Docker in a VM or an LXC brings:

• Process isolation for multi-tenant, regulated, or lab environments.
• Resource capping and guarantees via Proxmox’s CPU/mem limits.
• Backup and snapshot management (notably, near-instant ZFSL snapshots).
• Mixed kernel stacks: critical for workloads such as Kubernetes-in-Docker or GPU-accelerated ML.

Running Docker “bare-metal" on Proxmox (i.e., directly on the host), while possible, is discouraged: it complicates upgrades, backup strategies, and node composability.

LXC vs. KVM VM for Docker – Technical Analysis

LXC Containerized Docker (Linux ≥5.15)

Advantages:

• Minimal overhead; LXC containers share Proxmox’s kernel.
• Fast startup, efficient resource sharing.
• Quicker snapshots/restore (good with ZFS/BTRFS).

Drawbacks:

• Kernel is fixed by Proxmox host—limits use of certain modules, AppArmor, or custom drivers (e.g., NVIDIA kernel DKMS).
• Nested containerization is finicky; unprivileged LXCs block many Docker subfeatures due to user namespace mapping.

KVM VM

Advantages:

• Full guest kernel flexibility—run any distro, enable custom drivers (SR-IOV, GPU passthrough, etc.).
• Better isolation: mitigates “noisy neighbor" effects and secures against LXC kernel exploits.
• Friendlier for commercial support scenarios (VM-level DR, migration, etc.).

Drawbacks:

• Overhead: ≈10% CPU/memory penalty vs LXC in synthetic testing.
• Slower backup and restore, though mitigated by VM snapshots.

Conclusion:
Routine containerized services (CI runners, stateless apps, minor databases): LXC (privileged).
Demanding workloads, complex network/storage, or device passthrough (CUDA, ROCm): use KVM-based VMs.

Practical: Configuring Docker in LXC

Proxmox caveats:

• Unprivileged LXC (unprivileged=1) + Docker = permission errors (failed to create shim task: OCI runtime error: permission denied).
• Use privileged LXC (unprivileged=0) with nesting enabled.

Example LXC Config

# Create privileged container from Ubuntu 22.04 template
pct create 122 local:vztmpl/ubuntu-22.04-standard_22.04-1_amd64.tar.zst -unprivileged 0 -features nesting=1 -cores 4 -memory 8192 -net0 name=eth0,bridge=vmbr0
pct start 122
pct exec 122 -- bash

Install Docker (inside LXC):

apt update
apt install -y docker.io
systemctl enable --now docker
docker run --rm hello-world

Note:
docker-compose (legacy) or docker compose (plugin) may require additional packages.

Known Issue:
Running LXC with apparmor on strict may block Docker’s networking. Disable AppArmor or loosen profiles as needed, but document this change for auditing.

VM-Based Docker: When More Isolation is Needed

Provision VM (Debian or Ubuntu 22.04 LTS) via Proxmox GUI/qm CLI. Ensure:

• VirtIO SCSI storage controller.
• Sufficient CPU flags passed for nested virtualization if running dind (docker-in-docker) or Kubernetes.
• Optional: PCI(e) passthrough for GPU/DPU use.

Sample VM cloud-init drive for seamless CI deployments.

Storage Strategy: Data Resiliency and I/O Optimization

• Data directory separation: Always mount /var/lib/docker on a dedicated disk or ZFS dataset.
• ZFS examples:

# On Proxmox host:
zfs create rpool/data/docker-lxc-122
pct set 122 -mp0 /rpool/data/docker-lxc-122,mp=/var/lib/docker

• Avoid overlaying Docker’s storage driver on Proxmox’s ZFS dataset-over-directory, to prevent performance issues.

• Note: Docker’s default configuration (overlay2) is adequate for most use cases, but be ready to tune it for overlay/aufs, depending on kernel versions and workload mix.

Network Considerations – Deconflicting Bridges and Subnets

• Default Docker bridge (docker0) may clash with Proxmox’s NAT bridges (vmbr0, etc).
• For production: define a user macvlan network so containers are routable on the physical LAN, bypassing VM-level NAT.

docker network create -d macvlan \
  --subnet=10.10.10.0/24 --gateway=10.10.10.1 \
  -o parent=eth0 pub_net

• Alternatively, assign a static IP to the LXC/VM and rely on Proxmox’s firewall/SDN for macro-segmentation.

Gotcha:
TCP port forwarding at multiple layers (Proxmox NAT, LXC, Docker) creates convoluted network traces—document all mappings early.

Backup, Snapshot, and DR

• Use Proxmox’s native live snapshot (for LXC/VM) in tandem with application-aware Docker volume backups.
• For persistent data (Postgres, etc.), regularly export volumes out-of-band (docker cp or bind-mount external volumes).
• Avoid relying only on filesystem-level snapshots—restoring a “running” database snapshot yields corruption.

Monitoring and Troubleshooting

Host:

• pveperf, proxmox-backup-client, zfs list for I/O health.
• “Disk full” in Proxmox presents as:

  failed to start container: mkdir /var/lib/docker/containers/xxxx: no space left on device


LXC/VM:

• docker stats, journalctl -u docker, htop.
• For high inode churn (CI runners, artifact builds), monitor df -i.

Non-obvious tip:
Track Proxmox CT/VM disk images (qcow2, raw, or ZFS volumes) and trim regularly to avoid silent disk ballooning.

Automation: IaC for Repeatable Deployments

Leverage Terraform providers for Proxmox (danitso/terraform-provider-proxmox), paired with Ansible playbooks for Docker provisioning.
Parameterize LXC/VM resource sizing and cloud-init SSH keys.
Example:

resource "proxmox_lxc" "dockerhost" {
  hostname = "docker-lxc"
  ...
  features = {
    nesting = true
  }
}

Then in Ansible:

- name: Install Docker
  apt:
    name: docker.io
    state: present

Physical network IDs, bridge assignments, and storage constraints should be codified, not left implicit.

Summary Table

Final Notes

• Privileged LXC is best for simplicity in homelabs, but audit implications in enterprise.
• Always verify kernel version compatibility: Docker's overlay2 driver is impacted by older Proxmox base images.
• Consider alternatives: Containerd or Podman run comparably, but not all orchestration stacks are ready for them.
• For GPU workloads, passthrough plus nvidia-docker in a KVM VM is most reliable as of Docker 24.x and Proxmox 8.

For advanced deployment patterns—such as ephemeral CI/CD runners, or GPU batch compute nodes—additional nuances apply. Further optimization: avoid storing image caches in the same ZFS pool as containers’ writable layers if snapshot frequency is high.
